PTFE Coated Glass Cloth

Description

PTFE Coated fiberglass cloth is made of fiberglass base fabric and high quality PTFE coating. It is a high-performance material for its durability and versatility.

Fiberglass Fabric: This is a type of woven material made from glass fibers. It is valued for its strength, heat resistance, and stability, which make it suitable for various demanding applications.

PTFE Coating: PTFE stands for Polytetrafluoroethylene, a type of fluoropolymer. The PTFE coating provides additional properties such as exceptional chemical resistance, low friction, and a non-stick surface. It also enhances the fabric’s heat resistance, allowing it to withstand temperatures up to around 280°C (534°F).

When combined, PTFE-coated fiberglass fabric becomes highly resistant to extreme temperatures, chemicals, and abrasion, making it ideal for applications in industries like aerospace, automotive, and manufacturing. It’s commonly used in conveyor belts, insulation blankets, and protective covers, as well as in other high-performance settings where durability and reliability are crucial.

PTFE Coated Glass Cloth

Specification

Thickness: 0.08mm ~ 1.20mm

Width: 50mm~1500mm

Coating: Single Side or Double Side Coating.

Color: Gray, Brown, White, Customized

Packing: Plastic Films or Cartons , Pallets

Application

>> Industrial Conveyor Belts

>>Thermal Insulation Covers

>>Cooking and Baking

>>Protection and sealing

>> Aerospace and Automative

Hot Sale Specification

Product 15oz Silicone Coated Fiberglass Cloth
Weave Twill(4HS Satin)
Base fabric weight 430 g/m²± 10%
PTFE coating weight 80 g/m²± 10%
Total weight 510 g/m²± 10%
Thickness 0.40 mm ± 10%
Working temp. of base fabric 550 °C (1022 °F)
Working temp. of coating 260 °C (500 °F)
Width 1020 mm (40″), 1524 mm (60″)
Certification Reach, Rohs, UL94-V0, NFPA701 BS476
Color Silver Grey
PTFE Coated Glass Cloth
Product 16.5oz PTFE Coated Glass Fiber Cloth
Weave Twill(4HS Satin)
Total weight 560 g/m²± 10%
Thickness 0.40 mm ± 10%
Working temp. of base fabric 550 °C
Width 1500 mm (60″)
Certification Rohs / UL94-V0
PTFE Coated Glass Cloth
